3540 LiFe
Desktop charger LiFePO4 batt. max. 20A
Product Information
3-step charge control with current detection
Input voltage 198-264 VAC. 115 VAC versions available.
Fixed mains cable, 2-pin IEC 60320 available
Output terminal: cord w. open ends, XLR output plug for wheelchairs and scooters available
Wake up and low current start-up of deeply discharged batteries
Safety indication and protection: against reverse polarity, short circuit, charging battery packs with the wrong number of cells and safety timer run-out
Approvals
Medically certified
Safety: EN 60601-1 ed. 3.1
Home healthcare EN 60601-1-11 (fixed cord vers. only)
EMC: EN 60601-1-2 ed. 4
UL approved
Custom specifications on request
Charging parameters, connectors, cords, logo print, housing/open frame/IP rating and certificates. For more information: custom design info sheet
Notes
- Desktop unit
- Mounting bracket included
- With NTC input on request
- 2MOOP standard, 2MOPP available (3540P)
- Std DC output cord: open ends, L 1.1m, AWG 13, Black PVC, UL 1185
