Model NV184I

20A max out

  •  The core is made of iron powder
  •  Decrease the noise by using at 10kHz to 200MHz
  •  It is mainly applied in AC inductor, converter, switch power supplies, EMC filter, wind power, householding appliances
  • Working at -65℃ to +120℃
Request for quote ›

Core material: iron powder

Inductance: 150.0uH-1000.0uH

DC resistance(mΩ): 15.0-330.0

PCB Hole(mm): ø0.8/ø0.9/ø1.2/ø1.8/ø3.0

Operating temp: -65℃ to +125℃

Available versions

150uH / 20A
270uH / 12A
540uH / 5A
820uH / 2,5A
1000uH / 1,5A
