Model NV157S

20A max out

  • The core is made of sendust core
  • Decrease the noise by using at 10kHz to 200MHz
  • It is mainly applied in AC inductor, converter, switch power supplies, EMC filter, wind power, householding appliances
  • Working at -65℃ to +125℃
Request for quote ›

Core material: sendust

Inductance: 90.0uH-810uH

DC resistance(mΩ): 10.0-320.0

PCB Hole(mm): ø0.7/ø0.8/ø1.2/ø1.7/ø2.2

Operating temp: -65℃ to +125℃

Available versions

90uH / 20A
130uH / 12A
260uH / 5A
518uH / 3A
810uH / 1A
