Products › Transformers and Chokes › Chokes

Model CV250F Encap

5A max out

  • The core is made of Ferrite
  • Decrease the noise by using at 10kHz to 200MHz
  • It is mainly applied in AC inductor, converter, switch power supplies,EMC filter; wind power, householding appliances
  •  Working at -40℃ to +125℃
Request for quote ›
Notes:

Core material: Ferrite

Inductance: 470uH-10.0mH

DC resistance(mΩ): 40.0-150.0

PCB Hole(mm): ø1.2

Operating temp: -40℃ to +125℃

Available versions

2.2mH / 5A
3.3mH / 4A
5.3mH / 3A
6.8mH / 2.5A
10mH / 1A

Downloads

TECH SPEC OF CV250F Encapsulated.pdf
