Products › Transformers and Chokes › Chokes

Model CV130F

4A max out

  • The core is made of Mn-Zn Ni-Zn
  • Decrease the noise by using at 100kHz
  • Increases the anti-EMI ability
  • Operating temp. -40℃to +125℃
Request for quote ›
Notes:

Core material: Mn-Zn Ni-Zi

Inductance: 3.0mH

DC resistance: 35mΩ-5.0mΩ

PCB Hole(mm): Ø0.9/Ø0.8

Operating temp: -40℃ to +125℃

Available versions

3mH / 3.2A
3mH / 4.0A

Downloads

Tech Spec of CV130F.pdf
