Model CV148F

1,39A max out

  • The core is made of Mn-Zn Ni-Zn
  • Decrease the noise by using at 30kHz to 300MHz
  • Increases the anti-EMI ability
  • It is mainly applied in LED driver and power of telecoms which need compact size
  • Working at -40°C to +125°C
Request for quote ›

Core material: Mn-Zn Ni-Zn

Inductance: 2.2mH-68.0mH

PCB Hole(mm): Ø1.0

Operating temp: -40°C to +125°C

Available versions

2.2mH / 1.39A
3.3mH / 1.27A
6.8mH / 1.06A
10mH / 0.96A
15.0mH / 0.77A
22mH / 0,6A
27mH / 0.53A
30mH / 0.46A
33mH / 0.39A
47mH / 0.33A
68.0mH / 0.28A
